食品行业
Hawk品牌提供各种高品质的食品行业专用泵， 工作压力范围介于150至200巴之间。在本部分，您将找到使用高度可靠和耐用的材料和技术制造的产品，符合卫生和消毒方面的现行法规的要求。
泵 食品行业
配件 食品行业
双法兰电动发动机
双法兰电动机
B3 / B14型电动机
B3 / B14型电动机
| 代码 | 发动机结构形式 | 重量 | 额定功率 | 速度 | 电压 | 用于泵系列 | |
|---|---|---|---|---|---|---|---|
| Kg | HP | KW | RPM | ||||
| 1.099-413.0 | IEC100 | 21.0 | 4.0 | 3.0 | 1450 | 230/400V | NMT Car Wash, NMT高温, NHDP 120-C, NHDP 150-C, NHDP 200-C, NMT - Car Wash Heavy Duty, NMT Chemical, NMT Stainless Steel Chemical, NHDP Chemical, NHDP Stainless Steel Chemical |
| 1.099-414.0 | IEC100 | 23.0 | 5.5 | 4.0 | 1450 | 230/400V | NMT Car Wash, NMT高温, NHDP 150-C, NHDP 200-C, NMT - Car Wash Heavy Duty, NMT Chemical, NMT Stainless Steel Chemical, NHDP Chemical, NHDP Stainless Steel Chemical |
| 1.099-416.0 | IEC112 | 33.0 | 7.5 | 5.5 | 1450 | 230/400V | NMT Car Wash, NMT高温, XLTI高温, NHDP 200-C, NMT - Car Wash Heavy Duty, NMT Chemical, NMT Stainless Steel Chemical, NHDP Chemical, NHDP Stainless Steel Chemical |
法兰
电动发动机联轴法兰
| 代码 | 发动机结构形式 | 用于泵系列 |
|---|---|---|
| 1.099-528.0 | H90 B14 | NHDP洗车, NHDP 120, NHDP 150, NHDP 200, NHDP Chemical, NHDP Stainless Steel Chemical |
| 1.099-529.0 | H100/112 B14 | NHDP洗车, NHDP 120, NHDP 150, NHDP 200, NHDP Chemical, NHDP Stainless Steel Chemical |
| 1.099-530.0 | H100/112 B14 | NMT, NPM, NMT Car Wash, NMT高温, NMT 镀镍, NPM镀镍, NLTI, NMT - Car Wash Heavy Duty, NMT Chemical, NMT Stainless Steel Chemical |
| 1.099-531.0 | H132 B14 | NMT, NPM, NMT Car Wash, NMT高温, NMT 镀镍, NPM镀镍, XLTI, XLTI高温, PXI 350, XXT, NLTI, XLTI Atex, PXI 500, NMT - Car Wash Heavy Duty, NMT Chemical, XLTI Chemical, XLTI Stainless Steel Chemical, NMT Stainless Steel Chemical, PXI Heavy Duty |
| 1.099-532.0 | H160 B5 | XLTI, XLTI高温, PXI 350, XXT, XLTI Atex, PXI 500, XXT高温, XLTI Chemical, XLTI Stainless Steel Chemical, PXI Heavy Duty |
弹性联轴器
电动发动机弹性联轴器
泵支架
泵支架
| 代码 | 用于泵系列 |
|---|---|
| 1.099-687.0 | NMT, NPM, NMT Car Wash, NMT高温, NMT 镀镍, NPM镀镍, NHDP-HY, NMT - Car Wash Heavy Duty, NMT Chemical, NMT-HY, NPM-HY |
工具箱
Hawk工具箱 用于热水泵和不锈钢泵的套件
| 代码 | 用于泵系列 |
|---|---|
| 1.904-744.0 | NHDP洗车, NHDP 120, NHDP 150, NHDP 200, NHDP 120-C, NHDP 150-C, NHDP 200-C, NHDP-G, NHDP-G1, NHDP-HY, NHDP 200-NEMA, NMT Chemical, NHDP Chemical, NHDP Stainless Steel Chemical |
| 1.099-667.0 | NMT, NPM, NPM-GR, NMT Car Wash, NMT高温, NMT 镀镍, NPM镀镍, NMT - Car Wash Heavy Duty, NMT Stainless Steel Chemical, |
| 1.099-665.0 | XLTI, XLTI高温, PXI 350, XXT, NLTI, XLTI Atex, PXI 500, XXT高温, XLTI Chemical, XLTI Stainless Steel Chemical, PXI Heavy Duty, MPX Heavy Duty |
| 1.099-669.0 | MXT, MXT高温, MPX 350, MPX 500, MXT Chemical, MXT Stainless Steel Chemical |
| 1.905-635.0 | GXT, GXT高温, GPX, TXT, TPX |
| 1.905-137.0 | NHDP Chemical, NHDP Stainless Steel Chemical |
| 1.904-299.0 | NMT高温, NMT Chemical, NMT Stainless Steel Chemical |
| 1.099-963.0 | XLTI高温, XLTI Chemical, XLTI Stainless Steel Chemical |
| 1.904-248.0 | XXT高温 |
| 1.905-136.0 | MXT Chemical, MXT Stainless Steel Chemical |
卓越的维护套件
| 代码 | 用于泵系列 |
|---|---|
| 1.905-591.0 | NHDP洗车, NHDP 120, NHDP 150, NHDP 200, NHDP 120-C, NHDP 150-C, NHDP 200-C, NHDP-G, NHDP-G1, NHDP-HY, NHDP 200-NEMA, NHDP Chemical, NHDP Stainless Steel Chemical |
| 1.904-414.0 | NMT, NPM, NPM-GR, NMT Car Wash, NMT高温, NMT 镀镍, NPM镀镍, NMT - Car Wash Heavy Duty, NMT Chemical, NMT Stainless Steel Chemical, |
| 1.905-659.0 | XLTI, XLTI高温, PXI 350, XXT, NLTI, XLTI Atex, PXI 500, XXT高温, XLTI Chemical, XLTI Stainless Steel Chemical, PXI Heavy Duty, MPX Heavy Duty |
| 1.904-418.0 | MXT, MXT高温, MPX 350, MPX 500, MXT Chemical, MXT Stainless Steel Chemical |
| 1.905-636.0 | GXT, GXT高温, GPX, GXX, TXT, TPX, TXX |
